Alien X – Mobile C-Arm

Make and model: EUROCOLUMBUS ALIEN X – mobile X-ray device with C-arm,
Year of production: 2022,
Generator power: 25 kW,
Detector: Flat, 30 x 30 cm (VARIAN/VAREX),
X-ray tube: Dual focal spots 0.3/0.5 mm, anode capacity 400 kHU,
Software: Angiography Package,
Condition: Used, fully functional,
Warranty: Valid until 24/10/2024,
Documentation: Technical passport, warranty card, technical card, periodic inspection,
The equipment comes from: Closed Modernmed Clinic in Warsaw.

Key technical features
Working efficiency comparable to angiographic devices and stationary hemodynamics,
C-arm movement – ​​manual, mechanized, hybrid,
EPD anti-collision system on both sides – active and intelligent,
4K monitor with adjustable position,
Compact, separate control trolley with double console ETS15-18,
Lamp cooling system: WAD + EHC,
EPB power system – high power at standard power conditions,
Possibility to save 4 C-arm positions,
Proximity sensors on the entire surface of the FPD and lamp,
Easy cleaning, durable construction, modern ergonomics,
Footswitch included.

Key Features
The hybrid movement system – mechanical and motor,
enables precise maneuvering of the arm in all conditions,
Intelligent EPD anti-collision system – with proximity sensors on the lamp and detector side
that stops movement before it comes into contact with the patient or equipment,
Advanced VARIAN/VAREX flat panel detector – precise imaging supported
by modern data processing software,
WAD cooling system and EHC heat control – maintain optimal operating temperature,
preventing the X-ray tube from overheating,
The latest generation X-ray tube – made of TZM (titanium-zirconium-molybdenum),
ensures higher thermal and mechanical resistance,
EPB power system – an independent energy source for peak loads, without overloading the electrical grid.

Reliability and safety
The Alien X guarantees uninterrupted operation even in demanding clinical environments.
All components—from cables to painted surfaces—are designed for intensive use,
easy disinfection, and longevity.
