Amada PULSAR 2415NTA4 FANUC

AMADA PULSAR 2415NTA4
2008

4000 Watt
X-Axis Workpiece Movement
Y-Axis Cutting Head Movement
Simultaneous 3-Axis Control (X, Y, Z) and B Axis
FANUC AC Servo Drive Motors (X, Y, Z, B)
61" Y-Axis Maximum Sheet Size
198" X-Axis Maximum Sheet Size with One Reposition
61" Y-Axis Travel
99" X-Axis Travel
11.8" Z-Axis Travel
0.78" B-Axis Travel
787 IPM Maximum Cutting Speed
3,149 IPM Maximum Table Speed per Axis
4,454 IPM Maximum Table Speed (Vector)
787 IPM Maximum Z-Axis Speed
0.0004"/20" Positioning Accuracy
0.0004" Repeatability
727 lbs Maximum Material Weight
3 Material Clamps
66" Y by 21" X Work Chute
4 Assist Gas Ports, Part Program Selectable
125.0" x 150.0" x 95.0" Machine Size
18,700 lbs Machine Weight Including Laser Resonator
208 VAC, 3 Phase, 60 Hz, 10 KVA Electrical Requirements
