Arter H-30

Magnetic Chuck Diameter: 30″
Swing Inside Guards: 33″
Maximum Work Height: 10″
Wheel Head Stroke Maximum: 17″
Vertical Travel of Knee: 25″
Angular Tilt of Table: ±10°

Standard Wheel Size: 16″ x 2″ x 8″
Wheelhead Traverse Variable: 0 – 10 FPM
Table Speed Variable: 30 – 125 RPM
Power Feed Adjustable: 0.0001″ – 0.0015″
Table Slide Positioning: 61 PM

Main Spindle Motor: 10 HP
Electro-Magnetic Chuck, 5/8″ Chuck Life
Variable Hold Neutrifier
Hydraulic Over-the-Wheel Dresser with Micrometer Adjustment
Power Table Elevation: Auto Incremental Upfeed
Auto Incremental Up-Feed
Angular Table Adjustment
Automatic Cycling with Indicator Lights
BiJur Trabon Automatic Lubrication System
External Hydraulic System
External Coolant Tank with Pump
Total Machine Power: 30.25 HP
Wired for 3/60/575 Volts, 50 Amp Service

Approximate Weight: 13,000 lbs
Approximate Floor Space: 114″ F-B x 68″ W x 80″ H
Exceptional Condition and Appearance
