Cauliflower and broccoli florets kit

Length – 6,000 mm
Width – 3,500 mm
Height – 1,400 mm

Technical data:
Drive – gear motor – 0.37 kW – 900 rpm
The loading part (top) is used for loading and feeding whole cauliflowers
or broccoli for a floret machine
Diameter – Ø 2,050 mm;
Two loading entrances
The unloading part (lower) is used to receive the cut corncobs and

sorted products from the rosette machine (bottom)
External path width – 350 mm;
3) Two floret machines

Overall dimensions of one rosette machine:
Length – 1,100 mm
Width 1,220 mm
Height – 1,050 mm

Technical data of one rosette machine:
Upper turntable with 6 holes and grippers on
whole cauliflowers and broccoli
Hole diameter – Ø 240 mm;
2 drives with gear motors – 0.55 kW
They have 4 transport wheels with locks

All elements of the set are connected to one control cabinet
Made entirely of stainless steel.
