Chinese made GA163D Sectional warper 300 Cm
Ref :
2727796-1-GO
Condition :
Used
Manufacturer :
Chinese made
Model :
GA163D Sectional warper
Width :
300 Cm
Year(s) :
2008
Quantity :
1
Location :
Seller or machines location:
ASIA (North East)
ASIA (North East)
Last check :
02 Mar. 2026
Warping width 2000 ~ 3600mm
Warping speed : 0 ~ 800 m/min
Drum dia. : 1026 mm
Drum taper length : 1010
Angle pf taper : 9'
Whole - movable Beaming Unit
Beaming Roller width 4300mm
Beaming flange 800mm ~1000mm dia
Beaming speed : 0 ~ 100.0 ~ 200m/min.
Strip positioning : Automatically
Touch screen
Inverter control : 37kw new
Main motor 45Kw
Creel : 480 pos
