CHM 1700 SK

Single Knife Precision Sheeter
* Cutting accuracy -+/- .020”
* Single (fixed knife) cutting unit with Siemens Color Touch Screen control
* Capability to cut paper and board from 35 gsm to 550 gsm (note that 550 gsm is the total maximum basis weight that can be cut including all rolls combined)
* Maximum paper width - 65"
* Maximum paper length - 45"
* Minimum paper length - 18”
* Maximum skid height - 72"
* Maximum skid weight - 5,000 lbs.
* Maximum roll diameter – 72”
* Maximum roll weight – 5,000 lbs.
* Two (2) shaftless roll stands
* Two (2) sets of Montalvo air brakes
* Four (4) sets of 3" to 12” tapered chucks
* Gross weight – 28,000 lbs
* Max cutting speed: 750 ft per minute (subject to sheet length & sheet density)
