Cincinnati 90CBII CNC Press Brake 90 tons

Press force: 90 tons
Bed & ram length: 8 ft
Distance between housings: 8′ 6 3/4″
Stroke: 8″
Open height: 15″
Closed height: 7″
Throat clearance: 7″
Approach speed: 260 ipm
Forming speed: 10–20–80 ipm
Return speed: 280 ipm
Bed top width: 3.5″
Main motor power: 15 hp
Factory retrofit CNC control system
CNC back gauge system
Transducer position feedback system
Narrow filler block installed
Light curtain safety system
Electric foot switch
Pedestal palm button station
Interlocked construction design
Clevis mounted self-aligning cylinders
Approximate machine weight: 13300 lb
Approximate dimensions (L×FB×H): 8′ 6.5″ × 50″ × 110″
