Collin ZK 25 compounding line

Working hours: 1.378
Screw dimension: 25 mm
Screw L/D: 48
Connected load: 36 kW
Dimensions (LxWxH): 5.000 x 1.200 x 2.200 mm
Weight: 1.350 kG

Line configuration:
– 2x Gravimetric feeding systems from Coperion
– 1x Side feeding with two possible placements
– 2x liquid dosing
– 1x vent port for degassing, including vacuum pump
– Filament die with 1 cavity
– Filament die with 4 cavities
– FECON system for monitoring process data
– Silicon conveyor belt with active air cooling
– Pelletizer with adjustable speed
