CUTTER SUCTION DREDGER Maximum Dredging Depth 26 m

CUTTER SUCTION DREDGER
Year: 2010

Length Overall 97 m
Beam 18.2 m
Molded Depth 5.2 m
Design Draft 3.5 m
Diesel Oil Tank Capacity 835 cubic meters
Fresh Water Tank Capacity 200 cubic meters
Ballast Water Tank Capacity 730 cubic meters
Classification Society / Notation ZC / Offshore navigation area
Crew Capacity 29
Maximum Dredging Depth 26 m
Minimum Dredging Depth 6 m
Nominal Max Production Capacity 3,500 cubic meters/hr
Discharge Distance 4,000 m
Diameter of Suction Pipe 850 mm
Diameter of Discharge Pipe 800 mm

Inboard Pumps Make/Model CCCC Shanghai Dredging / JT170-800B
Inboard Pumps Power 2,150 kW x 2
Inboard Pumps Water Flow 13,000 cubic meters
Inboard Pumps Head 55 m

Pump Engines Make/Model Ningbo C.S.I / GW8320ZC7B
Pump Engines Power 3,089 kW x 2

Submerge Pump Make/Model CCCC Shanghai Dredging / JT170-800B-SX
Submerge Pump Power 1,350 kW
Submerge Pump Water Flow 13,000 cubic meters
Submerge Pump Head 38 m

Pump Engine Make/Model Lanzhou Electric Motor Factory / YKS630-6-7H
Pump Engine Power 2,000 kW

Rated Voltage 3,000 V

Shaft Generator Diesel Engine Make/Model Ningbo C.S.I / G8300ZC2B
Shaft Generator Power 2,500 kW

Alternator Make/Model Lanzhou Electric Motor Factory / TFXW630-4-H
Alternator Power 2,300 kW
