Doosan DCM 2750F II 4 Axis

DOOSAN DCM 2750F II
2019

Number of tables 1
Table width 86"
Table length 177"
Table load capacity 55,000 lb
Distance between columns 106.2"
Spindle nose to table top 64.9"
X-axis travel 207.7"
Y-axis travel 125.9"
Z-axis travel 27.5"
W-axis position 43.3"
Rapid traverse X-axis 787 ipm
Rapid traverse Y-axis 787 ipm
Rapid traverse Z-axis 590 ipm
Cutting feedrate 393 ipm
Spindle speed 6,000 RPM
Spindle taper 50
Number of gear ranges 2
Main motor power 33.5 hp
Automatic tool changer capacity 60
Tool diameter 5.12"
Tool diameter with empty adjacent pocket 9.45"
Tool length 15.75"
Tool weight 55 lb
Machine weight 127,865 lb
Control FANUC 31i-B CNC color control
Linear scales on X, Y, Z, W axes
90-degree angle head with 1-degree indexing
AAC swing 2-station head changer
Part program storage 8 MB
Through-spindle coolant 300 PSI (20 bar)
Chip conveyor
Rigid tapping
Handheld remote MPG
