Doosan Doosan Fanuc i-Series Control 6000 rpm DN SOLUTIONS Lynx 2100LSYA 5 Axis

X-axis travel: 205 mm (8.1 in)
Y-axis travel: 105±52.5 mm (4.1±2.1 in)
Z-axis travel: 560 mm (22 in)
B-axis travel: 560 mm (22 in)
C-axis indexing: Full C
Rapid traverse X-axis: 30 m/min (1181 in/min)
Rapid traverse Y-axis: 10 m/min (394 in/min)
Rapid traverse Z-axis: 36 m/min (1417 in/min)
CNC control: Doosan Fanuc i-Series Control
Max turning diameter: 300 mm (11.8 in)
Max turning length: 510 mm (20.1 in)
Through hole diameter: 61 mm (2.4 in)
Spindle speed: 6000 rpm
Spindle power: 20 HP (15 kW)
Spindle nose: A2-8
Chuck size: 6 in
Sub spindle: yes
Sub spindle speed range: 6000 rpm
Sub spindle motor: 7.5 HP (5.5 kW)
Sub chuck size: 5 in
Number of turret stations: 12
Live tooling: yes
Live tooling torque: 46 Nm (34 ft-lbs)
Rotary tool speed: 6000 rpm
Rotary tool power: 5 HP (3.7 kW)
Rotary tool torque: 24 Nm (17.3 ft-lbs)
Machine cutting hours: 3118
Machine dimensions: L 2880 x W 1710 x H 1920 mm (113.4 x 67.5 x 76 in)
Machine weight: 4150 kg (9150 lbs)
Tool presetter
Multiple live radial/axial toolholders
Collet chuck – main and sub spindle
Work light
Chip conveyor
Part pick-off
Part conveyor
Coolant system
LNS Alpha SL65-S magazine barfeeder
Manuals
