Flexo printer 8 1200 mm

Comiflex flexo printer
Mechanical and software upgrade: 2013
Central drum
8 colors
With gears
For paper and film
Materials: LDPE, CPP, BOPP, PET, paper up to 100 gsm
Material passage: 1280 mm
Printing width: 1200 mm
Print repeat: 340 – 800 mm
Mechanical speed: 300 m/min
Cast iron frame thickness: 120 mm
C.I. diameter: 1700 mm double walls
Two separate stations for for drying with electric resistance, drum and drying tube
Type cliche: 1,14 mm
Two positions unwinder mandrel 3’’ or 6’’
Two positions rewinder, mandrel 3’’ or 6’’
Motorised registrations from control panel
Double bracket unwinders diameter: 800 mm
Double automatic turret rewinder diameter 800 mm
In and out web guides
Camera view
Gears with sleeves: 1 x 350; 1 x 380; 1 x 400; 1 x 420; 1 x 435; 1 x 440; 1 x 450; 1 x 465; 1 x 480; 1 x 500;
1 x 520; 1 x 530; 1 x 540; 1 x 555; 1 x 575; 1 x 600; 1 x 650; 1 x 750
Gears with sleeves: 1 x 70; 1 x 76; 1 x 80; 1 x 84; 1 x 87; 1 x 88; 1 x 90; 1 x 93; 1 x 96; 1 x 100; 1 x 104;
1 x 106; 1 x 108; 1 x111; 1 x 115; 1 x 120; 1 x 130; 1 x 150
Gears without compatible sleeves: 4 x 78, 8 x 68, 8 x 72, 8 x 74; 8 x 94, 7 x 118
Aniloxes: 1 x 60/20; 1 x 100/18; 1 x 100/17; 1 x 120/13; 2 x 140/12; 1 x 180/9; 1 x 210/7,5; 2 x 240/6; 1 x 300/5; 1 x 300/4,2; 3 x 320/5
Machine can be started in case of serious interest
Immediately available
