Grecon Dimter OptiCut 204 R

The GreCon Dimter OPTICUT 204 R cross-cut optimizer is designed for precision cutting tasks.
The machine features a robust construction and a weight of approximately 3,500 kg.
It is equipped with a 9 kW motor that provides the necessary power for efficient operation.

This optimizer supports a maximum cutting length of 4,000 mm, with the ability to cut elements up to 200 mm.
The maximum cutting height is 100 mm and the cutting width can reach up to 260 mm.
The saw blade has a diameter of 500 mm, suitable for a variety of cutting applications.
The machine offers full optimization for length and value, allowing precise and efficient material usage.

Additional technical features include a maximum feed speed of 160 meters per minute
and an acceleration of 2 meters per second squared, ensuring smooth and fast processing.
Pneumatic pressure is applied to the material for stable cutting, and the system includes three ejectors for efficient material handling.
The machine is also equipped with discharge tables and a rotating table to facilitate material flow and positioning.
