Grob G552 5 Axis

X travel 800 mm
Y travel 1020 mm
Z travel 970 mm
A axis -185° to 45°
B axis 360°

Rapid traverse X 65 m/min
Rapid traverse Y 50 m/min
Rapid traverse Z 80 m/min
Rapid traverse A 25 rpm
Rapid traverse B 50 rpm

CNC control Heidenhain TNC 640
Max spindle speed 30000 rpm
Spindle nose HSK-A63
Tool magazine positions 140
Machine length 6452 mm
Machine width 2900 mm
Machine height 3271 mm
Machine weight 25700 kg
Operating voltage 400 V
Mains frequency 50 Hz
Control voltage 230 V
Maximum connected load 54 kVA
Rated current 77 A
Pre-fuse 100 A
Minimax CO2 high pressure fire extinguishing system
Knoll KF 600E/2600 coolant system
Camfil oil mist separator
Bielomatik central lubrication system
Liquidtool
Measuring probe
Set of HSK-40 tool holders
Complete operational documentation
