Homag Optimat KL 79/A20/S2

The edge banding line is in satisfactory working condition, fully operational and ready for production.

Installed Units:
• A20/S2 gluing station (edge thickness up to 20 mm)
• Edge feed magazine
• Front/rear end trimming units (two saw modules)
• Top and bottom trimming units
• Corner rounding units (two heads)
• Profile scraper units (top/bottom)
• Glue joint scraper
• Buffing/polishing units
• Pneumatic control and vacuum extraction system

Technical Data (from manufacturer specifications):
• Feed speed: 18–24 m/min
• Edge thickness: 0.3–20 mm
• Workpiece thickness: 12–60 mm
• Minimum workpiece width: 55 mm (22 mm thickness) / 100 mm (60 mm thickness)
• Machine length: 10,115 mm
• Weight: ~6,200 kg
• Power supply: 400 V, 50/60 Hz
• Compressed air: 8 bar
