Index CNC CONTROL 5000 rpm R 200 5 Axis

X-Axis Travel (Subspindle): 600 mm
Z-Axis Travel (Main Spindle): 390 mm
Z-Axis Travel (Subspindle): 390 mm
Y1-Axis Travel: ±80 mm
Y2-Axis Travel: ±80 mm
C-Axis Resolution: 0.00014°
B-Axis Swivel Angle: 230°
Index C200-4D SL Control
2 Milling Heads (Full 5-Axis)
Sub Spindle
Rotary Tools
Linear Scales on All Axes
Coolant Through Spindle (80 bar)
Tool Breakage Control
Barfeeder Interface
Parts Catcher
Air Filter
Maximum Turning Diameter: 65 mm
Turning Length: 120 mm
Bar Capacity: 65 mm
Spindle Bore: 85 mm
Spindle Speed: 5000 rpm
Spindle Motor Power: 35.5 / 27.5 kW
Spindle Torque: 170 / 125 Nm
Milling Spindle Speed: 18000 rpm
Milling Spindle Motor Power: 11 kW
Milling Spindle Torque: 19 Nm
Rapid Traverse X: 45 m/min
Rapid Traverse Y: 15 m/min
Rapid Traverse Z: 45 m/min
Tool Magazine Capacity: 80 HSK A40
Static Tool Positions: 6 (VDI 25)
Spindle 1 Chuck: 165 mm
Spindle 2 Chuck: 165 mm
Collet Chuck Main Spindle
Collet Chuck Subspindle
Short Bar Loader IRCO ILS RBK 10016
Chip Conveyor
Parts Conveyor
Machine Dimensions: 3730 x 2920 x 2580 mm
Weight: 16.3 t
