Italpack Pack 100 DVP automatic packing line
EUROPE (Central and Eastern)
Purchased as second hand from Italpack after full restoration in February 2024.
Weights : 1kg
Pack Type : Square bottom kraft paper bags
Type of closure : By means of Hot-Melt glue to obtain “box shape” pack
Production rate : 75 - 80 bags/min on 1kg
Main power : 380 V - 50/60 Hz
Aux. power : 24 Volts
Operators Required : N° 01 for surveillance
Certification : CE Certification
Product : Sugar
TECHNICAL FEATURES:
1: Electro-mechanical function
2: 380 V - 50/60 Hz
3: Installed kw 10 - (380 V - 50/60 Hz)
4: Compressor required for PACK 100 only: 300 normal litre/min
5: Hot glue consumption - 4 kg per 8 working hours
6: Dimensions: mm 3370 length - mm 2080 width - mm 3160 height
7: Compressor required for packer plus an eventual (automatic or semi-automatic)
bundling unit: 500 normal litres/min
8: Weight - 2900 kg.
9: Standard colour - RAL 1013 pearl white and ITALPACK light blue
