Karlville KV-400 DSUP Pouch making line

Supports a wide variety of pouch formats including:
3-side-seal pouches (from 1 or 2 webs) Stand-up pouches (from 1 or 3 webs)
2-side-seal pouches (from folded web) With or without zippers -
Folded gussets
Max Pouch Width: 400mm Max Pouch Height: 400mm Gusset Depth Range: 15–65mm

Machine Specifications:
Max mechanical speed: 200 cpm
Production speed: ~130 cpm (material dependent)
Max material width: 420mm
Material range: PET, ALU, PE laminated with PP or PE
Material thickness: 55–200 microns

Included Equipment:
Top + bottom unwinders with pneumatic clamping
Servo-driven draw, 1nip, sealing and cooling stations
Bottom gusset folding and zipper unwinder
Flying knife cutting system with anti-static bar
Eye-mark sensor and ultrasonic edge guide
Conveyor exit system
Tear notch, euro hole & tack-hole punches
Doy style and straight sealing dies
Zipper sealing and cooling dies
Multiple cross sealing dies and silicon holders

Over £100k of extras included:
Ultrasonic zipper crush station,
vacuum punch waste removal, gusset folding upgrade, chiller, and more.

Additional kit on the machine:
Second Longitudinal station - smaller zipper pouches and separate skirt seal for multi web pouches.
Additional Cross seal station for running mono materials
Double cut function
Additional Trim rewinder
Mono Gusset Seperator
Additional punch bridge
