Kramatorsk Engine Lathe Variable KJ1910

Ref : 2268492-3-GO
Condition : Used
Manufacturer : Kramatorsk
Type : Engine Lathe
Spindle Speed : Variable
Model : KJ1910
Year(s) : -
Quantity : 1
Location : Seller or machines location:
AMERICA North (USA-Canada-Mexico)

Kramatorsk KJ1910

Swing Over Bed 63 in 1600 mm
Maximum Workpiece Length 248 in 6300 mm
Maximum Drilling Diameter 39.37 in 990.6 mm
Spindle Power 165 hp 125 kW
Spindle Speed 1 - 320 RPM Infinitely Variable
Power Existing
Additional Chuck workholding range: 8"- 49.2" inch (200 - 1250 mm) diameter, workpiece weight capacity using two open roll supports: 132,000 lbs (60,000 kg), size range in closed backrest: 8"- 31.5" inch (200 - 800 mm), size range in open backrest: 24.8"-54.3" inch (630 - 1380 mm), pressure head speed range: .125 - 500 infinitely variable, pressure head spindle bore diameter: 7 inch ( 182 mm), pressure head motor power: 100 HP (75 kW) DC, headstock speed ranges: 3, pressure head speed ranges: 2
Machine Length 903 in 22950 mm
Machine Width 172 in 4375 mm
Machine Height 105 in 2670 mm
Weight 222400 lbs 101091 kg
