Kupfermühle 60

Four-sided planer, thicknesser, jointer with 6 heads
Max planing width 610 mm
max planing height on both sides 200 mm
max planing height four sides 100 mm

in advance:
2 rubber pulling rollers +
2 sprocket rollers +
metal pulling roller +
input shaft, pulling, toothed +
pawl +
pressure +
pulling shaft, toothed 2szt
pressure +
610mm planing shaft, 4 cutter 7,5kW
pressure +
pulling roller, smooth, metal +
pressure +
profiling shaft 7,5kW
pressure +
rubber pulling roller

from down:
planing shaft, 35mm axis, 130mm axis length 2,2kW
lead bar 2szt
introductory table +
pulling shaft, smooth +
610mm planing shaft, 4-knife (2 knives installed) 7,5kW
2 pulling shafts, smooth +
sliding roller, metal, split +
lateral pressure +

in the back:
side spindles + clamps 2
1) vertical right 100mm 4kW
2) vertical left 100mm 4kW
diameter of spindles 35 mm
spindle adjustable up / down, right / left +

adjustable rollers in the bottom worktop +
electrical setting of planing thickness +
6 kinds of feed speeds 7/9/11,5/14/18/23m/min
feed motor 3,1kW
diameters of the extraction pipe 3 × 120, 3x160mm
dimensions length / width / height 3150x1900x1600mm
weight around 3500kg
