MAN Lithoman II 1

Web Offset Book Press
Cut Off: 2 x 416 mm
Cylinder Circ: 832 mm (32.76”)
Non-Print Gap: 14 mm
Max Web Width: 1360 mm
Min Web Width: 505 mm
Max Mech Speed: 25,000 CPH
Running Direction: Left to Right

Equipment Comprising of:
(1) MEG DME-2-50-S Zero Speed Splicer c.1993
• Reel Ø 1270mm

(1) MEG Infeed
(1) E&L Web Guide

(1) MAN Lithoman Printing Unit
• Dahlgren Dampening
• Betz Ink Supply

(1) Dampening Water Circulation
(1) E&L Web Guide

(1) MAN Folder Superstructure for 1 Web
• Slitter
• Air loaded angle bars
• Driven ribbon pull roller
• Web compensators
• 1 Air loaded former

(1) MAN Pinless Book Folder
• Collect / Non-Collect
• Delivery for 1⁄4 fold

(1) Planatol Fold Softening System
(1) Main Control Desk
(1) Electrical Drive System
(1) Plate Bender
(1) Set of Drawings and Manuals

Post Press
(1) Exit Conveyors
(1) Stream Alignment Jogger
(1) Civiemme ST320 Log Stacker c.1997
(1) Civiemme PL86 Palletizer c.1997

PRODUCTION
This press is designed for the production of:
‘B Format’ Long Grain: (129 x 196mm) (5” x 7.8”)
