Mazak VTC-20C 3 Axis

MAZAK VTC-20C
Year 1997

Control Mazatrol M plus
Number of axes 3
X travel 1660 mm
Y travel 510 mm
Z travel 510 mm
Rapid traverse X 24000 mm/min
Rapid traverse Y 24000 mm/min
Rapid traverse Z 20000 mm/min
Tool taper SK 40
Spindle speed max 7000 rpm
Spindle power 11 kW (at 10-40/100% duty cycle)
Tool magazine type chain
Number of tool stations 48
Max tool diameter 80 mm
Max tool diameter without adjacent tools 110 mm
Max tool length 350 mm
Max tool weight 8 kg
Max workpiece weight 1000 kg
Table size 2000 x 510 mm
Infrared measuring probe
Tool measurement system
Tool breakage control
Tool life monitoring
Partially enclosed work area
Chip conveyor
Internal coolant supply
Coolant unit
Main fuse 46 A
Machine dimensions 4900 x 3000 x 2700 mm
Machine weight 7320 kg
