MBF Complete Bottling Line

Production (hour): 9.500 bph
Direction: Counterclockwise
Speed:
9,000 BPH with Cork cap
9,500 BPH with aluminum screw cap
Ape depalletizer
Model: Depal 2010
Year: 2015
Speed: 60 layers/hour
Automatic operation
Type of operation: by layer
Workable pallet dimensions: 1200 mm x 800 mm; 1200 mm x 1000 mm
Automatic layer removal system
Pallet warehouse
MBF triblock
Model: Synchrofill 1440.40F1/1440.40LV/360.6R/360.5V
Year: 2015
Directions: Counterclockwise
Rinser Single treatment
40 clamps
Electric adjustment height
Fixed nozzle
Type of treatment: water
Filler
40 valves
Electric tank height adjustment
Filling type: light vacuum
Mechanical valve
Valve functions: gas injection before filling, automatic level adjustment system by operator’s panel
Corker 6 heads for natural straight corks.
Cork size: minimum height 34 mm; maximum height 54 mm
Electric head height adjustment
Vacuum system, gas injection and 2nd vacuum before capping
Corker 5 heads for aluminum screw cap
Electric head height adjustment
Gas injection system before capping
General triblock data
Bottle diameters supported: minimum Ø 55 mm; maximum Ø 100 mm
Minimum height: 180 mm; maximum height: 360 mm
OMAR drying tunnel
Model: Asco 4
Year: 2015
Air blade drying system
Robino & Galandrino capsuling machine
Model: Poker z 6/12
Year: 2019
Electric head adjustment
6 thermal heads
12 rolling heads
Long range storage
Cavagnino & Gatti labelling machine
Model: cg-cll-12-3xpsh-cf-6-mp
Year: 2015
Rotary
Clockwise
Electric adjustment heads
12 plates
Electronic cam
3 adhesive stations
No. 2 vertical unwinders
Label presence control
Additional ironing of outgoing bottles
Ape carton erector
Model: Form 3000
Year: 2015
Closure by hot glue (Nordson)
Carton dimensions:
• Minimum length: 130 mm; maximum: 470 mm
• Minimum width: 130 mm; maximum: 380 mm
• Minimum height: 280 mm; maximum: 600 mm
Carton storage capacity: 250 (depending on the thickness of the carton)
Ape case packer
Model: Inca 2010
Year: 2015
Carton formats: 3×2, 4×3, 6×4
Carton dimensions:
• Length: minimum 200 mm; maximum 420 mm
• Width: minimum 130 mm; maximum 380 mm
• Height (with open carton): minimum 250 mm; maximum 590 mm
Nr. 1 adjustable head for 3×2 and 4×3 boxes (min and max bottle sizes Ø 62-108 H 200-400)
Nr. 1 fixed head for 4×3 and 6×4 boxes for 187 ml Ø 52.2 bottles
Ape carton closer
Model: CH 2010 HM
Year: 2015
Closure by hot glue (Nordson)
