Davis Standard, Merritt 4.5" Single Screw Extruder

Ref : 2744955-6-CP

Condition : Used

Manufacturer : Davis Standard, Merritt

Model : 4.5" Single Screw Extruder

Year(s) : -

Quantity : 1

Location : Seller or machines location:
AMERICA North (USA-Canada-Mexico)

4.5" Merritt/Davis Standard Single Screw Extruder, Air Cooled,
24:1, 150hp AC
5 Barrel Zones, 4 Die Zones
Feed Throat: 5" x 5"
150 HP WEG Severe Duty AC Motor, Frame 444/5T
Model: 15018EP3GRB445T,1780 RPM, Enclosure: TEFC
New WEG AC Drive
460/3/60
With Clamp and Spare Screws
Approximate Dimensions: 164" L x 66" W x 84" H
10-12 WEEK LEAD TIME for New Drive & Heater band
