MG AK 410 C

MG AK 410 C
Year of manufacture 2010

- Robust electro-hydraulic 3-roll bending machine
- All 3 rolls directly driven via planetary gears
- Conical rolling possible by tilting the rolls
- Parallelism of the side rolls via torsion shafts
- Double-sided bending
- Diameters of up to 1.1 times the top roll diameter are possible
- Forged and hardened rolls with a hardness of 53-55 HRC
- Low-maintenance, stable machine design
- Permanent lubrication of all bearings
- Sturdy welded steel construction
- 1 mobile control panel
* with digital position indicators for the side rolls
* Control via joysticks
- 2 bending speeds selectable
- Electro-hydraulic folding bearing for easy adjustment Pipe removal
- Pressure gauge / pressure indicator for the rollers
- Safety device (safety lanyard with switch unit)
- Operating instructions (PDF)

sheet width: 4100 mm
plate thickness: 10.0 mm ST
pre-bending: 8.0 mm ST
diameter of upper rolls: ~ 350 mm
side roll diameter: ~ 300 mm
bending speed: ca. 2.0 + 5.0 m/min
oil volume: 125 Liter
voltage: 380 V
total power requirement: 11.0 kW
weight: 9150 kg
range L-W-H: 5600 x 1700 x 1500 mm
