Mighty PRO-4216AG

X-axis travel: 4200 mm
Y-axis travel: 1600 mm
Z-axis travel: 800 mm
Table to spindle distance: 5.9" – 37.4"
Distance between columns: 1700 mm
FANUC 0i-MF control
Wireless manual pulse generator
Hydraulic counterbalance for headstock
Spindle taper: CT50
Spindle speed: 0 – 6000 rpm
Spindle motor: 30 HP
Tool capacity: 40 tools
Maximum tool length: 400 mm
Maximum tool weight: 20 kg
Maximum tool size (adjacent empty): 245 mm
Tool size (full capacity): 125 mm
Table size: 86.6" x 43.3"
Maximum table load: 26,450 lbs
Ground T-slotted table
Spindle chiller
Coolant system
Dual chip augers to single chip conveyor
Hardened and ground box ways
Machine weight: 62,500 lbs
