Milltronics VK-1 Vertical 4000 RPM

MILLTRONICS VK-1
2008

Table size 9" x 49"
Table travel (X-axis) 30"
Saddle travel (Y-axis) 11"
Quill travel 5"
Knee travel 16"
Ram travel 12"
Spindle taper R8
Spindle speeds low range 60 - 500 RPM
Spindle speeds high range 500 - 4000 RPM
Spindle diameter 3.375"
Head swivel side to side ±90 degrees
Head tilt front to back ±45 degrees
Approximate dimensions 80"L x 70"W x 82"H
Approximate weight 3,000 lbs
Centurion 7200 SLS control (2-axis)
Skill level select software
Conversational & G/M code
10" LCD display
Ballscrews for X & Y travels
AC servo motors for X & Y travels
Ground solid ways with Turcite surfaces
Lubrication system
Flood coolant system
5 HP motor
Vector spindle drive
