Mitsui MSG-250H2AH

Table working surface 8" x 19"
Maximum surface ground 9-1/2" x 20"
Maximum distance between table surface and spindle center 22-1/2"
Longitudinal travel 20"
Cross travel (automatic) 9-1/2"
Cross travel (manual) 10"
Vertical travel 16"
Infinitely variable longitudinal feeds 5 - 68 FPM
Auto cross feed per stroke 0.02" - 0.05" IPM
Auto vertical feed increments, ten steps 0.0001" - 0.001"
Rapid cross feed rate 2 - 17 IPM
Elevating handwheel graduations 0.0001"
Cross feed handwheel graduation 0.001"
Cross feed vernier 0.0001"
Approximate machine weight 3,490 lbs
Automatic incremental downfeed of grinding wheel
Hydraulic longitudinal and power cross feeds
Roller bearing table
Hardened and ground ways on table, carriage/saddle, and column
Automatic one-shot lubrication system
Grinding wheel 8" x 1/2" x 1-1/4"
Spindle drive 2 HP / 3/60/460 Volt, super-precision
2-axis digital readout ("ANILAM")
Electromagnetic chuck 8" x 18"
Variable hold neutralizer ("SMART" series)
Coolant system with guarding, hoses, tank, and pump
Wheel cover with dust inlet ("VAC-U-GUARD")
Work light
External hydraulic system with tank, pump, and valving
Machine wired for 3/60/230 Volt electrics
