Mori Seiki MSG 501 (Fanuc) 5000 rpm SL-153SY 5 Axis

X-axis travel: 215 mm
Y-axis travel: 490 mm
Y-axis stroke: +40 / -30 mm
Z-axis travel: 520 mm
C-axis indexing precision: 0.001°

Control: MSG 501 (Fanuc)
Main bar capacity: 56 mm
Main spindle speed: 5000 rpm
Main spindle power: 7.5 kW
Main spindle nose: A2-5
Sub spindle speed: 5000 rpm
Sub bar capacity: 43 mm
Sub spindle nose: A2-5
Driven tool speed: 3000 rpm
Driven tool power: 3.8 kW
Rapids: 24 m/min
Main turret positions: 12
Live turret positions: 12
Distance between spindles: 750 mm
Main collet chuck: Hainbuch SRANNTOR
Sub chuck: Forkardt 140 mm 3-jaw chuck
Includes LNS Quick Load Servo II Barfeed
Includes overhead gantry
Includes swarf conveyor
Includes component conveyor
Includes toolholders
Includes manuals
Machine weight: 7000 kg
Overall length including barfeed and stacker: 5600 mm
Overall width with rear swarf conveyor: 3048 mm
Height to top of gantry loader: 3048 mm
Barfeed dimensions (L x W x H): 2050 mm x 1500 mm x 1450 mm
