Muller BZE 800-25.3.1 800 t
Ref :
2800910-3-AW
Condition :
Used
Manufacturer :
Muller
Model :
BZE 800-25.3.1
Pressure :
800 t
Year(s) :
1974
Quantity :
1
Location :
Seller or machines location:
EUROPE (Western and Northern)
EUROPE (Western and Northern)
Press Force: 800 t
Distance Between Columns: 2560 mm
Stroke: 1050 mm
Control: Siemens S5
Distance Table/Blank Holder, Max Stroke Up: 1870 mm
Table Surface Area: 2500 × 1730 mm
Die Cushion Pressure Inside Table: 300 t
Stroke of Drawing Cushion in Table: 395 mm
Die Cushion Pressure in Pusher: 63 t
Stroke of Drawing Cushion in Pusher: 150 mm
Ram Surface: 200 mm
Die Cushion in Pusher: Hydraulic, Controlled
Die Cushion Inside Table: Hydraulic, Controlled
Total Power Requirement: 200 kW
Machine Weight: 150 t
Machine Dimensions: 4.95 × 3.3 × 10.2 m
Overhauled in 2005
