Nakamura Tome Fanuc 21i-TB 4500 rpm SC 200 LMY 3 Axis

Ref : 2803462-3-GO

Condition : Used

Manufacturer : Nakamura Tome

Controller : Fanuc 21i-TB

Spindle Speed : 4500 rpm

Model : SC 200 LMY

Nb Of Axis : 3 Axis

Year(s) : -

Quantity : 1

Location : Seller or machines location:
EUROPE (Western and Northern)

X-Axis Travel: 277 mm
Y-Axis Travel: 82 mm (±41 mm)
Z-Axis Travel: 500 mm
Control: Fanuc 21i-TB
Robot Interface
Chip Conveyor
Bar Capacity: 65 mm
Turning Diameter: 410 mm
Standard Turning Diameter: 275 mm
Turning Length: 500 mm
Main Spindle Speed: 4500 rpm
Main Spindle Power: 18.5 / 18.5 / 15 kW
Turret Stations: 12
Driven Tool Stations: 12
Driven Tool Speed: 6000 rpm
Driven Tool Power: 5.5 kW
Collet Chuck: Hainbuch
Total Power Requirement: 39.2 kVA
Machine Weight: 6.2 t
Machine Dimensions: 3.1 x 2.0 x 2.2 m
