Nakamura Tome Fanuc 31i-TA 6000 rpm WT 100 MM / Robot Loading 5 Axis

Ref : 2803454-3-GO

Condition : Used

Manufacturer : Nakamura Tome

Controller : Fanuc 31i-TA

Spindle Speed : 6000 rpm

Model : WT 100 MM / Robot Loading

Nb Of Axis : 5 Axis

Year(s) : 2008

Quantity : 1

Location : Seller or machines location:
EUROPE (Western and Northern)

X-Axis Travel Turret 1: 135 mm
Z-Axis Travel Turret 1: 503 mm
X-Axis Travel Turret 2: 135 mm
Z-Axis Travel Turret 2: 503 mm
C-Axis: Spindle 1 / Spindle 2
Control: Fanuc 31i-TA
Robot Interface
Chip Conveyor Right Discharge
Bar Capacity: 42 mm
Turning Diameter: 190 mm
Turning Length: 503 mm
Main Spindle 1 Speed: 6000 rpm
Main Spindle 1 Power: 11 / 7.5 kW
Sub Spindle 2 Speed: 6000 rpm
Sub Spindle 2 Power: 11 / 7.5 kW
Turret 1 Tool Positions: 12
Turret 1 Driven Tool Positions: 12
Turret 1 Driven Tool Speed: 6000 rpm
Turret 1 Driven Tool Power: 7.1 / 2.2 kW
Turret 2 Tool Positions: 12
Turret 2 Driven Tool Positions: 12
Turret 2 Driven Tool Speed: 6000 rpm
Turret 2 Driven Tool Power: 7.1 / 2.2 kW
Total Power Requirement: 53 kVA
Machine Weight: 5700 kg
Machine Dimensions: 2.3 x 1.6 x 1.94 m
