Oliver 4455

Used 22" Wide Single Planer. With 7 1/2 HP single phase TEFC motor wired 230 volts.
This Planer has the authentic Byrd Shelix head.
Sectional infeed roller and chip breaker apply uniform pressure on uneven stock, coupled with a driven outfeed roller to keep you stock moving smoothly.
Digital thickness readout for precise thickness settings. 3 V-Belt drive transfers power to drivetrain and cutterhead.
Magnetic controls with emergency off switch for safety.
Hinged access to cutterhead and feed rollers for quick set-up.
Easy access to motor, drive train, and gearbox for easy maintenance and adjustment.

Maximum Stock Width 22"
Maximum Depth of Cut 3/16"
Maximum Stock Thickness 9"
Minimum Stock Thickness 1/8"
Minimum Stock Length 10"
Dust Port Diameter 5"
CFM Required 900
Infeed Roller Diameter 3"
Outfeed Roller Diameter 3-5/16"
Bed Rollers 2, Adjustable
2-Speed Gear Box Feed 20 and 30 FPM
Cutterhead Speed 5,000 RPM
Cutterhead Diameter 3"
Table Support 2-Column
Table size 32 1/4" L x 23 3/4" W
Overall Dimensions 45" W x 32" D x 50" H
Weight 1,568 lbs.
