Polzer EVA - 6 E

Polzer Gluing Star
Multi-Level Gluing Press
6 gluing levels, each with 2 special heating plates
Gluing dimensions: 2100 mm x 1100 mm
With glue application station
With 2 lifting devices for loading and unloading the panels
With roller conveyor
Maximum workpiece thickness: approx. 50 mm
The panel is lifted pneumatically for unloading

Per level:
7 pneumatic pressure cylinders, 100 mm diameter,
100 mm stroke, pressure force: 740 kg per cylinder,
Movable pressure plate: 250 mm x 40 mm
2 cylinders for operating the upper heating plate
Insertion opening: 700 mm
2 electric heating plates
Each electric heating plate: 220/380V, 3 kW, thermostats: 0 – 120°C

Operating pressure 8–10 bar
Adjustable bonding temperature, ideally 50–65°C
Performance approx. 50 m²/h
With protective grille
External dimensions approx. 4000 mm x 4000 mm x 3600 mm
