Reiden RX 14 4 Axis

X-axis travel 1,800 mm
Y-axis travel 1,800 mm
Z-axis travel 1,210 mm
A-axis travel -15° to +105°
Rapid traverse 40 m/min
Table dimensions ø1,400 x 1,200 mm
T-Nut 22H7 / 100 mm
Swing clearance ø1,900 mm (limited up to 2,200 mm)
Max. workpiece weight 5,000 kg
Spindle speed 15,000 RPM
Spindle drive power 63/73 kW (100/40% ED)
Spindle torque 300/348 Nm (100/40% ED)
Cooling through spindle center bar 50
Tool holder HSK-A100
Tool magazine slots 92
CNC control Heidenhain TNC640
Electronic handwheel Heidenhain HR410
Chip conveyor
High pressure pump
Collision monitoring Heidenhain DCM
Direct measuring systems on all axes Heidenhain
Rinsing pistol
Automatic opening and closing door
Spindle offset sensor Micro Epsilon
Paper band filter system
Air through spindle selectable via M-function
Heidenhain HR550 FS electronic handwheel with radio transmission
Radio measuring sensor Blum TC60
Blum Novotest laser tool setting and breakage control
Oil and emulsion mist separator
Machine length 6,886 mm
Machine width 7,001 mm
Machine height 3,871 mm
Machine weight 42,000 kg
