Reignmac REIGNMAC

Four Side Planer
Min / max width of the workpiece 20 / 240mm
min / max height of the workpiece 8 / 160mm
number of spindles 4
1) horizontal lower 240mm 5,5kW
2) vertical right 160mm 5,5kW
3) vertical left 160mm 5,5kW
4) horizontal upper 240mm 7,5kW
all heads adjustable up / down, right left +
diameter of spindles 40 mm

- in advance:
6 introductory pulling, toothed rollers, including 2 double +
2 drawing rollers, smooth rubber +

- from down:
lateral pressure in front of and behind the roller in the lower table +
toothed, pulling, torsion input shaft in the lower table before the first spindle +
2 pneumatic side clamps +
metal, smooth, drawing-out roller +

all rolls pneumatically pressed +
length of the countertop 2180 mm
adjustable top / bottom top +
central lubrication +
electrical setting of planing thickness +
lifting engine 0,75kW
smooth regulation of feed speed on the inverter 6-30m / min
feed motor 3kW
feed on cardan shaft +
closed in the cabin +
diameters of the extraction pipe 4x150mm
dimensions length / width / height 3750x1750x1800mm
weight 3300kg
