Royal Master TG-12X4

Capacity (In-feed): 0.004" to 1.5" dia
Capacity (Thru-feed): 0.004" to 1.5" dia
Length Capacity: 12 ft on 0.5" dia
Grinding Wheel Diameter: 12"
Grinding Wheel Power: 7.5 hp
Grinding Wheel RPM: 2,040
Regulating Wheel Diameter: 6"
Regulating Wheel Power: 7.5 hp
Regulating Wheel RPM: 500
Control: CNC
Machine Dimensions: 24" x 48"
Machine Weight: 3,800 lbs
Coolant Tank: 40 gallons, 3 stage
Diamond Tool Wheel: 10" dia (min)
Work Wheel Dresser: 1 ct., Part# TG 199 105
Regulating Wheel Dresser: 1/3 ct., Part# TG 222 50
Main Drive Motor: 7.5 HP, 1,725 RPM, double end spindle
Coolant Pump: 1/6 HP, 3,450 RPM, 12 gal/min at 5 PSI
Hydraulic Pump: 0.5 HP, 1,725 RPM, 0.5 gal/min at 150 PSI
Hydraulic Tank Capacity: 3 gallons of Mobil DTE-24
Wired: 460V 3 Phase
In-feed Work Rest
Thru-feed Work Rest
Coolant Tank Pump
