Schelling Unimat Super 4

Technical details :
Cutting length (max.): 5,750 mm
Cutting height (max.): 120 mm
Cutting width (max.): 2,600 mm
Main saw diameter: 460 mm
Power: 27 kW (36.71 HP)

Description:
Machine type: fh6 580 HT260 ERB-L / MCS-Evolution / Win 10
Cutting length: 5.750 mm
Cutting width: 2.600 mm
Year of construction: 2007
Saw blade projection max .: 135 mm
Saw blade diameter max .: 460 mm
Main saw motor: 27 kW
Scorer aggregate
Scorer saw blade diameter max .: 200 mm
Package height max .: 120 mm
Package height min .: 3 mm

Saw aggregate forward: 6 up to 150 m / min
Saw aggregate backward: up to 150 m / min
Feeder: up to 80 m / min (Europe: forward 25 m/min

Number of clamps: 8 pcs grip push clamp
Clamp opening: 125 mm
Lifting / lowering device for clamps
Strip aligner before and after the pressure beam
Air cushion tables: 1 pcs. (2100 x 700 mm)
Turn table: 1 pcs. (5800 x 2200 mm) 90° turnable

Machine table:
heavy-duty steel construction „Closed Frame Construction“ machine table surface is precision machined
Machine table lips
Automatic cutting length adjustment
Lift table, max. panel width: 2600 mm
Feeding roller conveyor: 7100 x 2600 mm
Recesses for forklift trucks: 2 pcs
Frequency converter for feeding roller conveyor
Positioning stop: 2 pcs
Push-off trolley
Push-off device: 3 pcs
Book aligning device for longitudinal board edges: 3 pcs
Retaining device: 3 pcs
Roller table
Cross alignment stop at the roller table
This machine is in very good conditions and works very well.
The machine is reconditioned, checked and tested in our company.
Errors and alterations in the technical datas and informations excepted!
