Schroeder MHSU 4000/2.0

Sheet width: 4080 mm
Steel sheet thickness: 2.0 mm
Stainless steel thickness: 0.8 mm
Aluminum sheet thickness: 2.5 mm
Cutting angle: 1.3°
Strokes per minute: 34
Distance between columns: 4310 mm
Backgauge range: 15.0–750 mm
Table height: 820 mm
Control: ELGO NC
Engine power: 9.0 kW
Machine weight: 3600 kg
Machine dimensions (L × W × H): 5250 × 2200 × 1400 mm
Digital backgauge position display
Adjustable backgauge from front right
Target/actual value input
Continuous backgauge adjustment
Limit switch protection
Motorized backgauge
Welded steel frame construction
Compact machine layout
Support table with recessed grips
1× hold-down bar
1× side stop with T-slot and scale
3× front support arms
1× movable foot switch
Operating instructions
Pneumatic sheet holding device for thin material
