SCM Olimpic K 560 HP

Single-sided edgebanding machine, working from left to right
Panel thickness : 8 - 60 mm
Min. panel width : 95 (60) mm
Edge thickness : 0.4 - 8 (12) mm
Throughfeed : 12-18 m/min.
Compressed air : 6 bar
Machine length : 4800mm
Machine weight : 1840 kg

Motor driven bridge
Large touchscreen Eye-M front at eye level and swivelling
Front blocking pin
Motorised infeed-ruler
Diamond pre-milling
Upper glue box + 2nd upper glue box
Motorised pressure zone with 1 driven roller and 3 free rollers
2 cutting saws
Motorised fine milling
Double corner rounder milling
Motorised PVC scraper
Flat scraper
Polishing brushes with spraying device
