Spinner Fanuc 21i TB 5000 rpm TC 52-MC 3 Axis

SPINNER TC 52-MC
2004

Control Fanuc 21i TB
Program run time approx. 16031 hours
Control on time approx. 67540 hours
Max turning diameter 280 mm
Max turning length 400 mm
Max spindle speed 5000 rpm
Main spindle power at 10–40/100% duty 12 kW
Spindle bore 52 mm
C-axis at main spindle
Hollow clamping cylinder at main spindle
Tailstock dragged
Turret stations 12
Driven tools 12
Turret tool holder VDI 30
Turret axes X/Z
X travel 200 mm
Z travel 570 mm
Fully enclosed work area
Work area light
Prepared for oil/emulsion mist extraction
Chip conveyor
Coolant unit
Finished part outfeed conveyor
Finish-part pick-up unit
Bar loader/magazine available on request
Bar loader interface
Mains fuse 35 A
Machine weight approx. 4000 kg
