Star Fanuc CNC (typically Fanuc 18i-TB or 31i-A) 8,000 RPM SR-32J 8 Axis

X1-axis travel
Y1-axis travel
Z1-axis travel
C1-axis rotation

X2-axis travel
Z2-axis travel
C2-axis rotation
Optional Y2-axis travel

ControlFanuc CNC (typically Fanuc 18i-TB or 31i-A)
Bar capacity1.26 in (32 mm)
Max machining length (per chuck)12.6 in (320 mm)
Main spindle speedUp to 8,000 RPM
Sub spindle speedUp to 8,000 RPM
Main spindle motor5.5 / 7.5 kW (7.5 / 10 HP)
Sub spindle motor3.7 kW (5 HP)
Live tool speedUp to 5,000 RPM
Cross-drilling stations6 front + 4 rear live tools
Back-working tools8 stations (drilling, milling, tapping)
Total tool capacity28+ tools
Coolant systemFlood coolant / high-pressure coolant ready
Bar feederFMB
Chip conveyorLNS
Dimensions (L × W × H)≈ 100″ × 55″ × 65″
Weight≈ 6,500 lb (2,950 kg)
