Stromab TR 600

Cross-Cut Saw
The machine is in GOOD CONDITION and FUNCTIONAL
Shortening saw for shortening lumber – slats – prisms – according to the setting of the stops
Hydraulic movement of the saw blade, safety two-handed operation
Machine according to CE standards
Safety fence on the workbench
Work table 2000 mm on the right side of the saw blade with idle 90 mm rollers
Work table 2000 mm on the left side of the saw blade with 90 mm idler rollers
Saw blade with a diameter of 550 mm
Side stop on the fence

Technical data:
Motor saw blade: 12 HP / 9 kW
Engine power of the hydraulic unit: 1.5 HP / 1.1 kW
Saw blade with a max. diameter: 600 mm
Saw spindle speed: 3000 rpm
Working height above the ground floor: 850 mm
Working pressure: 8 Bar
Cutting capacity: max. width 610 mm

Cutting width with a thickness of 30 mm = 610 mm
Cutting width with a thickness of 60 mm = 590 mm
Cutting width with a thickness of 100 mm = 540 mm
Cutting width with a thickness of 120 mm = 510 mm
Cutting width with a thickness of 140 mm = 470 mm
Cutting width with a thickness of 160 mm = 420 mm
