SW (Schwäbische Werkzeugmaschinen) BA 600-2 3 Axis

Travel X: 600 mm
Travel Y: 600 (975) mm
Travel Z: 500 mm
Rapid traverse X/Y/Z: 45/45/45 m/min
Acceleration X/Y/Z: 2.5/2.5/2.5 m/s²
Feed force X/Y/Z: 15000/15000/15000 N
Control: Siemens 840 D
Tool taper: HSK-A100
Spindle speed: 10000 RPM
Spindle power (S1/S6): 2x38 kW
Spindle torque (S1/S6): 2x363 Nm
Spindle front bearing diameter: 100 mm
Spindle configuration: 2 horizontal milling spindles
Spindle distance: 600 mm
Tool magazine: 2x40 stations
Max. tool diameter: 100 mm
Max. tool diameter (no adjacent tools): 250 mm
Max. tool length: 350 mm
Max. workpiece weight: 20 kg
Chip-to-chip time: 4.9 s
Workpiece changer: 2-fold automatic
Swivel units for clamping bridge: 2 pcs.
Swivel unit: NC-controlled
Rotary tables: 2 pcs. NC-controlled on one clamping bridge
Rotary table diameter: 340 mm
Clamping bridge supports: included
Hydraulic clamping pressure: 250 bar
Additional clamping circuits: 6 pcs.
Workpiece clamping: air-monitored
Tool breakage monitoring: Toolinspect
Working area: fully enclosed
Working range door: automatic sliding
Work area lighting: included
Extraction prep: central oil/emulsion mist
Chip conveyor: included
Coolant unit: included
High pressure pump: 70 bar
Tool management panel: additional
Warning lamp: included
Central oil lubrication: automatic
Operating voltage: 3x400/50 V/Hz
Machine dimensions (LxWxH): 5150x8650x4200 mm
Machine weight: 20000 kg
Spindle hours: approx. 9320
Shifts run: 2–3 shift operation
