SW (Schwäbische Werkzeugmaschinen) BA W04-22 5 Axis

X-axis travel: 400 mm
Y-axis travel: 500 (775) mm
Z-axis travel: 425 mm
Max rapid traverse X/Y/Z: 100/100/100 m/min
Max acceleration X/Y/Z: 14/14/20 m/s²
Feed force X/Y/Z: 10000/10000/2x5000 N
Linear glass scales: X/Y/Z/A(U)/C1(C2)/W1(W2)
Linear drive: X/Y/Z
Tool taper: HSK-A 63
Max spindle speed: 17,500 1/min
Max spindle power 10-40/100% duty: 35/26 kW
Max spindle torque 10-40/100% duty: 80/60 Nm
Spindle diameter in front bearing: 80 mm
Number of horizontal milling spindles: 2
Spindle distance: 400 mm
Air-monitored tool clamping
Pneumatic tool taper cleaning in milling spindle
Torque support for multi spindle drilling heads
Chain-type tool magazine: 2x60 stations
Max tool diameter: 80 mm
Max tool diameter without adjacent tools: 160 mm
Max tool length: 300 mm
Max workpiece weight: 10 kg
Chip-to-chip time: 2.75 s
Pallet changer: 2 fold
Max workpiece weight per pallet: 450 kg
Number of swivel units for clamping bridge: 2
Swivel unit NC-controlled
Rotary tables NC-controlled (5th axis): 4 pcs, 2 per swivel unit
Bridge dimensions: 1030 mm
Workpiece swing diameter: 550 mm
Clamping bridge supports: 2
Hydraulic clamping: 250 bar
Additional clamping circuits: 4 pcs
Air-monitored workpiece clamping
IR-measuring probe
Fully enclosed work area
Automatic sliding door for loading area
Light in working area
Oil-/emulsion mist extraction unit
Scraper-type chip conveyor
Discharge height chip conveyor: 1200 mm
Machine operates/operated with emulsion
Internal coolant supply
Flush gun
Coolant unit with paperband filter
High pressure pump: 70 bar
Modem for remote diagnosis and TeleService
Tapping without compensation chuck
Additional control panel for tool management
Warning lamp
Air supply: 6 bar
Operating voltage: 3x400/50 V/Hz
Total power requirement: 133 kVA
Transport dimensions (LxWxH): 3680x5100x3250 mm
Space requirement (LxWxH): 4350x7000x3100 mm
Machine weight: 14,500 kg
