Toshiba BP-130.R22 5.12

Reference #31714
Toshiba BP130.R22, 5.12" CNC Table Type Horizontal Boring Mill

FEATURES:
Tosnuc 888 4-Axis CNC Control
60-Station Automatic Tool Changer
Built-In Full B-Axis Rotary Table
Full Chip & Splash Enclosure

CAPACITY:
Spindle Diameter ...................... 5.12"
Taper In Spindle ...................... CAT #50
Vertical Travel, Y-Axis ............... 90.55"
Cross Travel, X-Axis .................. 137.79"
Spindle Travel, Z-Axis ................ 27.55"
Column Travel, W-Axis ................. 62.99"
Table Size (Built In B-Axis) .......... 70.8" X 86.6"
Table Load Capacity ................... 44,000 LBS
Table Indexing B-Axis ................. 0.001 Degrees
Spindle Speeds (3-Ranges) ............. 5-2500 RPM
Rapid Traverse ........................ 393.70 IPM
Feeds ................................. .04-141 IPM
Overall Height ........................ 206"
Floor Space ........................... 293.3 x 374"
Machine Weight ........................ 92,400 Lbs

EQUIPPED WITH:
Tosnuc 888 4-Axis CNC Control
60-Station Automatic Tool Changer
Thru-Spindle Coolant
Built-In Full B-Axis Rotary Table
Full Chip & Splash Enclosure
Chip Conveyor
40 HP/30 HP Spindle Motor

NOTES:
Inspect Under Power
