Trumpf TrumaBend 170 ton x 4100 mm CNC
Ref :
2730608-3-CP
Condition :
Used
Manufacturer :
Trumpf
Model :
TrumaBend
Pressure :
170 ton x 4100 mm CNC
Year(s) :
-
Quantity :
1
Location :
Seller or machines location:
EUROPE (Western and Northern)
EUROPE (Western and Northern)
Trumpf TrumaBend 170 ton x 4100 mm CNC
Technical data
Capacity: 170 ton × 4080 mm
Backgauge: CNC
Control: 2D Touch
Passage between uprights: 3680 mm
Max stroke: 215 mm
Max distance between table and ram: 385 mm
Depth of throat: 410 mm
Table width: 200 mm
Locking speed: 200 mm/sec
Working speed: 10 mm/sec
Returning speed: 135 mm/sec
Electric motor power: 29 kW
Length: 4620 mm
Depth: 1980 mm
Height: 2885 mm
Weight: 16.5 ton
Axes: Y1 / Y2 / X / R / Z1 / Z2 / V / I
Tooling: Wila Modufix tooling
