Tsugami CNC CONTROL 7000 rpm BS26(C)-III 3 Axis

Maximum bar diameter 1.023"
Spindle speed main spindle 200 - 7000 rpm
Main spindle indexing C-axis
C-axis increment 0.001°
Tool stations 6-OD, 4-ID, 5-ID/OD back/front working tools
Rotary tools 4 cross driven tools
Rotary tools 2 driven endworking tool positions
End working tool positions 4 (2 upper positions driven)
Max speed cross tool T10-T12 200 - 5000 rpm
Max speed cross tool T13 120 - 3000 rpm
Driven tool drive motor rating 1.5 HP
Turning tool size 5/8" square
Z1 main headstock in/out 8.21"
T1 OD tool slide up/down 5.90"
T3 backwork slide in/out 5.11"
X1 OD tool slide right/left 2.00"
X2 ID tool slide up/down 7.90"
Z2 ID tool slide in/out synchronous to Z1 7.88"
Sub spindle maximum diameter 1.023"
Sub spindle maximum drill capacity mild steel 3/8"
Sub spindle maximum tap capacity mild steel 5/16"
Sub spindle speed range 2000 - 7000 rpm
Sub spindle power rating 3.0 HP
Sub spindle indexing 5° increment
Horsepower main spindle 5.0 HP
Machine dimensions 72" x 46" x 67"
Machine weight 5300 lbs

Fanuc 18iTB CNC Control
Spego 64-8.5Z Barfeed
High Pressure Coolant
