Uteco ONYX 876 + 1 8+1 1500 mm

Print possibilityes 8+1
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1550
Print width (mm) 1500
Min print repeat (mm) 400
Max print repeat (mm) 760
Unwinder type Single position with roll loading system
Max reel diameter unwinder (mm) 1250
Rewinder type Single position with roll loading system
Max reel diameter rewinder (mm) 1250
Drying 2 zones on CI section, 2 blowing and two exhaust fans Tunnekl 4 mt length. One additional drying zone for stack unit downstream with 1 blowing, 1 exhaust and vertical drying good 2,5 mt . Electric heaters
Videocamera Yes , Selectra
Web guides Yes in and out Fife OPG
Inking system Closed chamber doctor blades
Anilox 9 ceramic anilox sleeves
Print Sleeves to be agreed
Flexo stack coating unit downsytream with Graqfykontrol register control
Carbon fiber printing mandrels
Materials Paper and board up to 200 gsm
Machine web tension 4- 60 kg
