Uteco Programm 1040 120 Cm
EUROPE (Western and Northern)
Manufacturer: Uteco
Model: PROGRAMM 1040
Year: 1998
Number of colors: 8
Print possibilities: 8+0;
Drive: Cardan
Trolley system: Yes
Web width (mm): 1250
Print width (mm): 1200
Print repeat range (mm): 400 -1000
Drying specifications:
Unit 1 extended 3000 mm hood 1 blowing fan Units
2- 7 single drier 2000 mm hood - Unit 8 double extended 2 x 3200 mm hods -2 blowing fans -
Automatic recirculation system with LEL control
Drying heat surce: Thermo oil heaters
Unwinder type: Turret automatic
Max reel diameter unwinder (mm): 1000
Rewinder type: Turret automatic
Max reel diameter renwinder (mm): 1000
Videocamera: BST Promark Hawk
Register controll: Grafykontrol CR13LT
Vyscosity control: Grafykontrol Coviistat F
Corona treatment : Yes Ferrarini Benelli Polimetal
Print cylinders: 1500
Additional informations:
Fire protection system on all stations
- 4 spare trolleys
- Peristaltic pump for cold seal application on unit 8 .
As optional, additional cylinders.
